Featured Speakers
Enabling Next-Gen Heterogeneous Systems Integration
The SEMI 3D and Systems Summit brings together semiconductor packaging leaders to explore the strategies and technologies driving next-generation heterogeneous systems integration.
This year's theme, Enabling Next-Gen Heterogeneous Systems Integration, focuses on exploring geopolitical dynamics, market trends, strategies to advance Europe's next-gen semiconductor solutions, and the latest technological advancements.
Expert-led sessions cover chiplet architectures, hybrid bonding, co-packaged optics, AI-driven system architectures, AR/VR, and wearable intelligence, with a strong focus on Europe's role in advancing design leadership, materials innovation, and the transition from lab to fab.
The exclusive exhibition area showcases industry leaders alongside innovative emerging companies, providing a platform for gathering and exchanging knowledge and foster collaborations.
Attendees will have several opportunities for B2B matching, including networking receptions, coffee breaks, lunches, and a unique Networking Dinner Cruise along the beautiful Elbe River.
Sponsors
Platinum
Gold
Event
Agenda
Registration, Networking Reception and Exhibition
Thursday, June 18
Summit Opening
Opening Remarks
This session examines shifting geopolitical dynamics and their impact on semiconductor supply chains, industrial policy, and Europe’s long-term technological resilience. Speakers will address global benchmarking, fab construction updates, and regional strategies. Insights will highlight where Europe stands today and what actions are needed to secure technology sovereignty across critical domains.
Opening Remarks by Session Chair
Heterogeneous Integration as a Strategic Lever for Europe’s Semiconductor Resilience
From Chip to AI Factory: A Five-Year Roadmap for Silicon Suppliers and Hyperscalers
From Portfolio to Products: Unlocking Europe’s Potential with Heterogeneous Integration
Networking Coffee Break
A Geographical Assessment of the Advanced Packaging Market
Panel Discussion
Biographies
Moderator
-E. Jan Vardaman
Panelists
-Rajesh Mandamparambil
-Gamal Refai-Ahmed
-Giorgio Cesana
Key Takeaways by Session Chair
Advanced packaging is central to enabling next-generation heterogeneous systems. This session spans fan-out packaging, OSAT strategies, supply chain considerations, and lab-to-fab technology transfer. Speakers will highlight European strengths, procurement challenges, and what is required to scale advanced packaging capacity regionally.
Opening Remarks by Session Chair
Primidi: A European 300 mm Fab Line OSAT serving Advanced Packaging Integration
Advanced Packaging at Scale: Bridging Innovation, Qualification, and High‑Volume Manufacturing
Scaling Advanced Packaging Inspection Through AI-Enhanced X-ray Analysis: Insights for Glass Panel Inspection
Advancing Redistribution Layer Plating for Enhanced Reliability and Performance
Networking Lunch
Advanced Panel Processing for Heterogeneous Integration on Large-Area Substrates
One Platform for Defect Inspection and 3D Metrology from Visible Light to Infrared
Lab-in-Fab: Accelerating 3D System Integration from RTO Research to Foundry High-Volume Manufacturing
Key Takeaways by Session Chair
Hybrid bonding is establishing itself as a cornerstone of high-density 3D integration. This session covers die-to-wafer and wafer-to-wafer bonding, DRAM stacking, reliability engineering, and integration challenges. Attendees will learn how hybrid bonding accelerates 3D architectures across memory, logic, and advanced packaging.
Opening Remarks by Session Chair
A New Era of Reworkable Hybrid Bonding
Process Control in W2W and D2W Hybrid Bonding
Implications of Hybrid Bonding on Lithography Alignment, Metrology, and Overlay Control
Key Takeaways by Session Chair
Networking Coffee Break
Co-packaged optics and photonic integration are key enablers of high-bandwidth communication, AI acceleration, and energy-efficient data movement. This session highlights European leaders in photonics, packaging, and quantum technologies. Speakers will address opportunities across optical interconnects, quantum photonics, and high-volume manufacturing.
Opening Remarks by Session Chair
Inside the Package: How CPO is Powering the Next Wave of AI
Co-Packaged Optics for the AI Infrastructure: A Roundup of Underpinning Technologies
ARCTIC: Enabling Scalable Photonic Detection for Co-Packaged Optics
High Density TSV Silicon Interposers as an Enabling Platform for Optical Datacom
Scalable MicroLED Optical Link Prototype Fabrication for the Next Generation Computing
Heterogeneous integration, Key to High Frequency Integration
Low-Pressure Plasma Processes for Photonic Packaging and Co-Packaged Optics
Key Takeaways by Session Chair
Networking Dinner Cruise
The Networking Dinner Cruise is set on a historic paddle steamer on the Elbe River, just a 5-minute walk from the Hilton Dresden Hotel. Following the final conference session, attendees will gather in the hotel lobby and be escorted to the pier by the SEMI Europe team onsite.
Friday, June 19
AI computing demands breakthroughs in scale, power efficiency, and memory bandwidth. This session covers wafer-scale engines, European AI accelerators, integrated photonics, and power delivery for high-performance AI systems. It also examines how Europe can position itself in the next wave of AI hardware.
Silicon Capacitors: A Ubiquitous Enabler in Advanced 3D-Integrated Data Center Systems
Advanced Packaging for AI Era - Challenges and Opportunities with Heterogeneous Architectures
Topic Coming Soon
Networking Coffee Break
Europe’s future competitiveness depends on strengthening semiconductor design capabilities. This session highlights chiplet architectures, CPU startups, 3D integration strategy, and the importance of building a strong design ecosystem. The speakers will present cutting-edge activities that position Europe as an emerging leader in system-level architectures.
Opening Remarks by Session Chair
GaN-on-Si Epiwafers with 200 and 300 mm Diameter are a Crucial High-Tech Material Enabling Breakthroughs for AI-Age Displays and AI Datacenter Infrastructure
Driving System Level Energy Efficiency in AI with Advanced Packaging and Heterogeneous Integration
Key Takeaways by Session Chair
Closing Remarks and End of 3D & Systems Summit
